GateLink WiFi Smart Door Security System – Complete Remote Access, Monitoring, and Management Solution

GateLink® WiFi Smart Door Security System – Complete Remote Access, Monitoring, and Management Solution

The GateLink® system revolutionizes door and gate access control by integrating remote operation, high-definition video monitoring, two-way audio intercom, and centralized management into a single, user-friendly platform. Designed for residential, commercial, community, and industrial applications, it allows administrators and users to control access, verify visitors, and manage multiple doors from anywhere in the world using a smartphone or computer. Beyond security and convenience, its unique built-in advertising platform creates new opportunities for revenue generation and information dissemination in communal spaces.

This all-in-one solution eliminates the need for multiple disparate systems, offering a cost-effective, scalable, and intelligent way to modernize any gate or door.

Core System Components & Technical Parameters

1. Main Controller: GL-WLAN-01

2. Camera Options:

Product Overview & Detailed Description

The GateLink® system is built around the GL-WLAN-01 smart controller, which serves as the brain of the operation. It connects to your existing gate motor or door lock via its relay outputs (OPEN, CLOSE, STOP, COM). Once connected to local WiFi, it establishes a secure, encrypted link to the dedicated JUTAI Cloud server.

Users interact with the system through the intuitive GateLink Mobile APP (available for iOS and Android) or a PC Management Software. The APP interface provides a unified dashboard showing live camera feeds, door status (Open/Closed/Obstructed), and immediate control buttons. A simple tap can open or close the gate, activate a "Hold Open" function, or initiate a two-way voice call with someone at the entrance via the integrated camera's microphone and speaker.

Key Functional Modules Include:

• Remote Access & Control: Unlock or operate gates from anywhere with an internet connection. Share temporary or permanent access rights with family members, employees, or visitors without physical keys or cards.

• Real-time HD Video & Intercom: See and speak to visitors in clear detail day or night before granting access, enhancing security and convenience for deliveries, guests, or facility management.

• Centralized Project/Group Management: A standout feature for property managers and businesses. Multiple GL-WLAN-01 controllers (e.g., for a community's main gate, side gates, and parking barriers) can be grouped into a single "Project" within the backend system. Administrators can manage all devices, user permissions, and view logs from one central console.

• Comprehensive Activity Logging: All door operations (who opened, when, via which method) are recorded with timestamps. The system also logs cycle counts for maintenance purposes.

• Integrated Advertising Platform: This innovative feature transforms the APP interface into a revenue-generating or information-sharing tool. Designated areas on the APP screen (e.g., below the video feed) can display images or video ads. Property managers or system owners can upload content and set custom click-through links (e.g., to a promotion, event page, or notice). Ad performance can be tracked through the backend analytics.

• Hierarchical Backend Management: The web-based backend offers robust tools for system administrators. Features include user/device management, role-based permission assignment (different access levels for super admins, property managers, residents), advertiser management, and in-depth analytics for both access patterns and advertisement engagement.

Application Scenarios

• Residential Complexes & Gated Communities: Provide residents with keyless entry via their phones. Property managers can remotely manage main and pedestrian gates, issue virtual keys to guests and service personnel, and use the advertising space for community notices, event promotions, or partner discounts.

• Commercial Office Buildings: Manage after-hours access securely. Employees can use the APP for entry, while reception can see and communicate with visitors before remotely unlocking the door. Facility managers can monitor access logs for all entrances.

• Industrial Parks & Warehouses: Enforce strict access control for different zones (main gate, loading docks, restricted areas). Record all entry/exit events for security audits and operational oversight. The system integrates with alarm inputs for enhanced security.

• Retail & Logistics Centers: Facilitate secure and efficient delivery access. Staff can verify and remotely open doors for authorized delivery drivers without leaving their post, improving logistics flow and security.

• Private Homes & Villas: Offer homeowners ultimate convenience and safety. See who is at the gate, communicate with them, and grant access from inside the house or while away. Share access with family members or housekeepers easily.

• Rental Properties (Airbnb/Vacation Homes): Eliminate the need for physical key exchange. Generate unique, time-limited access codes for guests directly through the APP, enhancing the guest experience and property security.

Why Choose GateLink® by JUTAI?

• All-in-One Integration: Combines access control, video surveillance, and intercom in one system, reducing equipment and installation costs.

• Scalable Architecture: Perfect for single doors or large multi-gate projects with its centralized group management.

• Revenue-Ready Platform: The built-in advertising module opens a new stream for monetization or community engagement.

• Professional Management Tools: Robust backend software provides the control and insights needed for commercial and large-scale deployments.

• Proven Technology: From Shenzhen JUTAI Comm Co., Ltd., a company with extensive experience in access and communication solutions.

Upgrade your entry points with intelligent control. Contact us today to discuss your GateLink® project or request a demo.
